Compression Load Cell GDS100

Robust digital heavy duty compression load cell produced in stainless steel and hermetically sealed to IP68 for installation under large silos, tanks, vessels and heavy duty applications



Capacity (Emax):



Industrial 0.25%

Overload Tolerance:

Up to 300% of rated capacity

Special Features
Dimensions (mm)
Special Features
  • Made in Denmark
  • Robust capacitive technology
  • Patented high reliability capacitive sensor
  • High tolerance of up to 400% overload
  • Stainless steel 1.4542 (17-4 PH)
  • Hermetically sealed to IP69K
  • Laser welded with Duplex 1.4462 stainless steel
  • Withstands welding voltages and ESD
  • Capacity (Emax): 100tons
  • Accuracy: Industrial 0.25%
  • Cable length up to 100meters
  • Load cell cable replaceable
  • Pre-calibrated with signal in kg or kN
  • Calibration independent of cable length
  • Easy mechanical and electrical installation
Dimensions (mm)


  • Silo weighing
  • Process weighing
  • Heavy duty applications
  • Level measurement
  • Offshore applications
  • Load cell cable length 10, 20, 50 or 100meters
  • Special PE load cell cable available for freezing low temperature (can be used down to -50 degrees Celsius)
  • Special Teflon load cell cable available for very high temperature (can be used up to 100 degrees Celsius)
  • Customized versions available
