LEGACY LOAD CELLS

Across the globe, our customers’ production relies on our digital loadcells. To keep them going, we keep a large inventory of spare parts to support older load cell generations that are no longer part of our product range. Contact us if you can’t find your Eilersen load cell type on this page or if you wish to hear about the advantages of upgrading to a newer version of one of our newer accurate and robust digital load cells.

Compact digital beam load cell for dynamic weighing, web tension measurement, process weighing, force measurement and general industrial weighing. This load cell is a short version of the BL beam load cell and produced in stainless steel and laser welded (IP68)

Type:

SBL

Capacity (Emax):

1, 2, 5, 10, 20, 30, 50kg

Accuracy:

High Precision 0.025%

Overload Tolerance:

500% at 2kg, 200% at 100kg capacity

Compact digital beam load cell for dynamic weighing, web tension measurement, process weighing, force measurement and general industrial weighing. This load cell is a short version of the SD beam load cell and produced in stainless steel and laser welded (IP68)

Type:

SDC

Capacity (Emax):

1, 2, 5, 10, 20, 30, 50, 100kg

Accuracy:

Industrial 0.10%, Precision 0.05%, High Precision 0.025%

Overload Tolerance:

500% at 2kg, 200% at 100kg capacity

The robust digital load cell type SDLX is produced in stainless steel and designed for the extremely though environment in lift systems for waste management with shock loads and vibrations. The load cell can also be used in general industrial weighing applications. OIML certified to class C3 according to OIML R60

Type:

SDLX

Capacity (Emax):

300kg

Accuracy:

0.025% C3

Overload Tolerance:

Up to 500% of rated capacity

Robust digital OIML certified beam load cell for dynamic weighing, process weighing and general industrial weighing. Application examples are belt scales, platform scales, small vessels, filling machines, process equipment etc. OIML certified (up to C6, MI10) according to OIML R60

Type:

SD

Capacity (Emax):

2, 5, 10, 20, 30, 50, 100, 150, 250, 500, 1000kg

Accuracy:

0.10% C1, 0.05% C2, 0.025% C3 og op til OIML klasse C6 (MI10)

Overload Tolerance:

500% at 5kg, 200% at 1000kg capacity

Robust digital heavy duty beam load cell produced in stainless steel and hermetically sealed to IP68 for process weighing, industrial weighing and tough applications such as on-board truck weighing, offshore, steel industry etc. OIML certified (up to C5) according to R60

Type:

SDM70

Capacity (Emax):

1000, 2000, 3000kg

Accuracy:

0.10% C1, 0.05% C2, 0.025% C3 og op til OIML klasse C5

Overload Tolerance:

Up to 500% of rated capacity

Robust digital heavy duty beam load cell produced in stainless steel and hermetically sealed to IP68 for process weighing, industrial weighing and tough applications such as on-board truck weighing, offshore, steel industry etc. OIML certified (up to C5) according to R60

Type:

SDM80

Capacity (Emax):

5000, 6000, 7000kg

Accuracy:

0.10% C1, 0.05% C2, 0.025% C3 og op til OIML klasse C5

Overload Tolerance:

Up to 500% of rated capacity

Robust digital compression load cell produced in stainless steel and hermetically sealed to IP68 for hygienic weighing installations, installations in tough environments and general process weighing

Type:

MD

Capacity (Emax):

50, 100, 150, 250, 500, 1000, 1500, 2000, 3000, 4000, 5000kg

Accuracy:

Industrial 0.10%, Precision 0.05%, High Precision 0.025%

Overload Tolerance:

500% at 50kg, 200% at 5000kg capacity

Robust digital compression load cell produced in stainless steel and hermetically sealed to IP68 for hygienic weighing installations, installations in tough environments and general process weighing

Type:

FD

Capacity (Emax):

6000, 8000, 10000, 12000, 15000, 20000, 25000, 50000kg

Accuracy:

Industrial 0.10%, Precision 0.05%, High Precision 0.025%

Overload Tolerance:

400% at 6tons, 200% at 50tons capacity

Robust digital heavy duty compression load cell produced in stainless steel and hermetically sealed to IP68 for installation under large silos, tanks, vessels and heavy duty applications

Type:

GDS100

Capacity (Emax):

100tons

Accuracy:

Industrial 0.25%

Overload Tolerance:

Up to 300% of rated capacity

Robust digital heavy duty compression load cell produced in stainless steel and hermetically sealed to IP68 for installation under large silos, tanks, vessels and heavy duty applications

Type:

GDS500

Capacity (Emax):

200, 300, 400, 500tons

Accuracy:

Industrial 0.25%

Overload Tolerance:

Up to 300% of rated capacity

Robust digital ATEX certified beam load cell for dynamic weighing, process weighing and general industrial weighing. Application examples are belt scales, platform scales, small vessels, filling machines, process equipment etc. in ATEX (Ex) environment. The load cell can also be used in non-ATEX (ex) rated area

Type:

BBLA (ATEX) BBL (Non-ATEX)

Capacity (Emax):

2, 5, 10, 20, 30, 50,100, 150, 250, 500, 1000kg

Accuracy:

Industrial 0.10%, Precision 0.05%, High Precision 0.025%

Overload Tolerance:

500% at 5kg, 200% at 1000kg capacity

Robust digital heavy duty ATEX certified beam load cell produced in stainless steel and hermetically sealed to IP68 for process weighing, industrial weighing and tough applications such as on-board truck weighing, offshore, steel industry etc. The BBMA70 load cell can be used in ATEX (Ex) and non-ATEX applications

Type:

BBMA70 (ATEX) BBM70 (Non-ATEX)

Capacity (Emax):

1000, 2000, 3000kg

Accuracy:

Industrial 0.10%, Precision 0.05%, High Precision 0.025%

Overload Tolerance:

Up to 500% of rated capacity

Robust digital heavy duty ATEX certified beam load cell produced in stainless steel and hermetically sealed to IP68 for process weighing, industrial weighing and tough applications such as on-board truck weighing, offshore, steel industry etc. The BBMA80 load cell can be used in ATEX (Ex) and non-ATEX applications

Type:

BBMA80 (ATEX) BBM80 (Non-ATEX)

Capacity (Emax):

5000, 6000, 7000kg

Accuracy:

Industrial 0.10%, Precision 0.05%, High Precision 0.025%

Overload Tolerance:

Up to 500% of rated capacity

Robust digital ATEX certified compression load cell produced in stainless steel and hermetically sealed to IP68 for hygienic weighing installations, installations in tough environments and general process weighing. The DLA compression load cell can be used in ATEX (Ex) and non-ATEX applications

Type:

DLA (ATEX) DL (Non-ATEX)

Capacity (Emax):

50, 100, 150, 250, 500, 1000, 1500, 2000, 3000, 4000, 5000kg

Accuracy:

Industrial 0.10%, Precision 0.05%, High Precision 0.025%

Overload Tolerance:

Up to 500% of rated capacity

Robust digital ATEX certified compression load cell produced in stainless steel and hermetically sealed to IP68 for hygienic weighing installations, installations in tough environments and general process weighing. The DMA compression load cell can be used in ATEX (Ex) and non-ATEX applications

Type:

DMA (ATEX) DM (Non-ATEX)

Capacity (Emax):

6000, 8000, 10000, 15000, 25000, 50000kg

Accuracy:

Industrial 0.10%, Precision 0.05%

Overload Tolerance:

Up to 400% of rated capacity

Robust digital ATEX certified heavy duty compression load cell produced in stainless steel and hermetically sealed to IP68 for installation under large silos, tanks, vessels and heavy duty applications. The DHA100 load cell can be used in ATEX (Ex) and non-ATEX applications

Type:

DHA100 (ATEX) DH100 (Non-ATEX)

Capacity (Emax):

100tons

Accuracy:

Industrial 0.25%

Overload Tolerance:

Up to 300% of rated capacity

Robust digital ATEX certified heavy duty compression load cell produced in stainless steel and hermetically sealed to IP68 for installation under large silos, tanks, vessels and heavy duty applications. The DHA500 load cell can be used in ATEX (Ex) and non-ATEX applications

Type:

DHA500 (ATEX) DH500 (Non-ATEX)

Capacity (Emax):

200, 300, 400, 500tons

Accuracy:

Industrial 0.25%

Overload Tolerance:

Up to 300% of rated capacity
